LED DRL fog lights for Toyota series

LED daytime running lights,car LED lights and led fog lights both 2 in 1 for toyota series

Item NO.:
CF201
price:
$40/60
Product Origin:
China
Shipping Port:
Guangzhou
Order(MOQ):
1

Inquiry now

Product Detail

Product Type: LED DRL fog light for Toyota series

car LED solution for European market

Applied for Toyota car models:

Toyota Corolla 2007 2008 2009 2010 2011 2012 2013 2014
Toyota Auris 2007 2008 2009 2010 2011 2012 2013 2014
Toyota Avensis 2007 2008 2009 2010 2011 2012 2013 2014
Toyota Camry 2010 2011 2012 2013 2014
Toyota Land Cruiser Prado 2009 2010 2011 2012 2013 2014
Toyota RAV4 2006 2007 2008 2009 2010 2011 2012 2013 2014
Toyota 4 Runner 2009 2010 2011 2012 2013 2014
Toyota Highlander 2008 2009 2010 2011 2012 2013 2014
Toyota Hilux 2009 2010 2011 2012 2013 2014
Toyota Matrix 2009 2010 2011 2012 2013 2014
Toyota Prius 2010 2011 2012 2013 2014
Toyota sequoia 2008 2009 2010 2011 2012 2013 2014
Toyota Sienna 2011 2012 2013 2014
Toyota Tacoma 2011 2012 2013 2014
Toyota Tundra 2007 2008 2009 2010 2011 2012 2013 2014
Toyota Venza 2009 2010 2011 2012 2013 2014
Toyota Yaris 2006 2007 2008 2009 2010 2011 2012 2013 2014

Toyota Verso 2006 2007 2008 2009 2010 2011 2012 2013 2014

LED DRL fog light compatible Toyota car models

Model No.:

CD272

Installation effect for Toyota series LED FRL fog lights

toyota led drl fog lights installation

Specification:

Electrical Characteristics
Working Voltage	10.0 to 16.0 V
Working Current	≤2.5 A (12.0 V)
Temperature Characteristics
Storage Temperature	-40 to 85°C
Working Temperature	-40 to 60°C
LED bulbs
LED chipset	(1 x 2.5W + 6 x 0.5W) x 2
Optical Characteristics
Luminous flux	180lm (fog lamp), 210lm (DRL)
Color Temperature	2,000 to 2,300K (fog lamp) and 6,000 to 7,500K (DRL lamp)
International Protection Level
Degree of international protection grade	IP65 (Fully Waterproof and Dustproof)
Package Characteristics
Gift Box Capacity	1 pairs
Gift Box Size	30.0 x 11.0 x 15.0 cm/ 11.8 x 4.5 x 6 inches
Gift Box Weight	1.1 kg
Carton Box Capacity	20 pairs
Carton Box Size	56.5 x 31.5 x 33.0 cm (L x W x H)
Carton Box Weight	23.5 kg

Fule saving of LED DRL daytime running lights

Features of Toyta LED DRL fog lights:


Easy installation for Toyota car LED DRL fog lights 1. CF201 LED DRL fog light is designed with the same dimension and installation mode as the OE fog light module.It is easy to install to the car, only need to replace the original fog lights, without any damage to the car. 2. For the fog light, H11 connector is ready to plug and play to the car.

	Fuel Saving for Toyota LED DRL fog 1. The rated power consumption of OE bulb is 55W. 2. DRL with 6 piece 0.5W wihte LED is 3W, LED fog light bulb is 2.5W, so the total power consumption for a pair is less then 11W. 3. In Europe, the cars are force to turn on the lights in daytime. For a example as 3 hours driving per day with head lights on and with a gasoline engine,the LED DRL will cost 9.9 litres gasline per year ,and the head lights will cost 66.4 litres gasline per year. So the DRL fog lights may save about 60 litres gasline per year.

High power LED bulbs for Toyota LED DRL fog lights 1. There is a 2.5W yellow lighting LED for fog light. And for DRL bulb are 6 piece 0.5W white lighting LED. The life time of LED is more than 30000 hours. 2. High luminous efficiency : more than 70lm/W.

	Heat sink for Toyota LED DRL fog light Aluminum heat sink keep the LEDs' temperature rising less than 15°C;.It will delay LED decay time.

PC lens for Toyota LED DRL fog lights 1.The lens is made by special PC, it can work under the high temperature of 105 degrees without deformation. 2. PC material is not easy to broken as glass, when it receives a an impact by stone, it will leave only a white spot.

LED DRL fog light, LED DRL fog lamp

Other CATEC's OE-fit LED DRL daytime running light models:

More CATEC LED DRL daytime running light models

Why select CATEC's LED DRL daytime running lights?

We, CATEC are specialized in auto lighting system and strong in R&D. By now, we have more than 70 special LED DRL daytime running light models. We keep launching 2 new models per month.

Reference:

1. More LED DRL daytime running light, please refer: http://www.catecglobal.com/LED-Running-Lights_c2

2. More LED DRL fog lamps, please refer: http://www.catecglobal.com/LED-DRL-Fog-Lights_c21

3. More Toyota series products, please refer: http://www.catecglobal.com/LED-DRL-for-Toyota-series_c37

4. Learn more about CATEC, please refer: http://www.catecglobal.com/About-CATEC_d1

Leave A Message

If you are interested in our products and want to know more details, please leave a message here, we will reply you as soon as we can.
